| Engine type | 173MN, 4-STROKE,SINGLE CYLINDER,WATER COOLED |
| Displacement | 275.6 CC |
| Max. Output | 13KW@7500 RPM |
| Max. torque | 22N.m@5000 RPM |
| Bore x stroke | 2.85 x 2.63 INCHES (72.5x66.8MM) |
| Max. Speed | 55KM/H |
| Climbing ability | 12° |
| Ignition | C.D.I |
| Starting system | ELECTRIC START |
| Battery | YTX12-BS 12V10AH |
| Carburetor Item | Y28V1L |
| Engine oil | SAE 10W/40 |
| Clutch | AUTOMATIC CTV |
| Gears | D-N-R |
| Driveline / Driving wheel | CHAIN / DUAL WHEEL DRIVE |
| Suspension F / R | DUAL A-ARM / THRU-SHAFT WITH DUAL SHOCKS AND DUAL A-ARM |
| Brakes F / R | DISC |
| Tires F / R | 22*7-10 /22*10-10 |
| Fuel capacity | 2.6 GAS |
| Weight, G.W. / N.W. | 335KGS/280 KGS |
| Max. load | 500 LBS |
| Wheelbase | 1800 MM |
| Dimension (L x W x H) | 2340*1400*1480 MM |
| Height to seat | 470 MM |
| Min. ground clearance | 150 MM |
| Pedal to seat back | 920-1060 MM |
| Shipping information | 40UNITS / 40'HQ |
| Package Size | 2300*1200*660mm |
|
