| L x W x H | 1950x1290x1430 |
| Package Size | 2000x1150x660 |
| Height to Seat | 400 |
| Min. Ground Clearance | 100 |
| Wheelbase | 1450 |
| Pedal to Seat Back | 820-960 |
| Type | JF210, 4-stroke, single cylinder, air cooled |
| Displacement (cc) | 208 |
| Output Max. Power (Kw) | 5.5KW /3600RPM (7.48HP) |
| Max. Torque | 11.2NM /2800RPM |
| Bore x Stroke (mm) | 70 x 54 |
| Climbing ability | 15° |
| Ignition | TCI |
| Starting system | Electric start or Pull start |
| Battery | YTX12-BS 12V10AH |
| Gasoline Tank Capacity (L) | 3.6 |
| Carburetor Item | P19 |
| Max speed (km/h) | 45 |
| Clutch | Exernal automatic CTV |
| Gears | D-R |
| Brakes, F / R | Hydraulic disk brake |
| Tires, F / R | 18x7-8 / 18x7-8 |
| Suspension, F / R | Dual A-arm / Thru-shaft with dual shocks and dual A-arm |
| Max load | 182kg (400LBS) |
| Gross / Net Weight (kg) | 202 / 182 |
|
